Ti 8MP WDR IP Turret Camera 2.8mm, Face Detection, 30FPS

$219.99

SKU: IP-5IRD8001-W-2.8 Categories: , ,

Description

Features
  • 8MP ( 3840 × 2160 ) H.265 coding
  • Max.resolution: 3840 2160
  • ICR auto switch, true day/night, ROI coding
  • 3D DNR, TRUE WDR, HLC, BLC, Smart IR, defog
  • 20~30m IR night view distance
  • One CVBS output; One MIC IN and one built-in MIC
  • Support smart phone, iPad, remote monitoring
  • DC12V/PoE power supply
  • P2P function optional
  • IP 67 ingress protection
  • Support three streams
  • Smart analytics: object removal detection, abnormal video signal detection, line crossing detection, and region intrusion detection,
Image Sensor 1 / 2.5 “CMOS
Image Size 3840 × 2160
Electronic Shutter 1 / 25 s ~ 1 / 100000 s
Minimum Illumination 0.068 lux @F2.0, AGC ON; 0 lux with IR
0.024 lux @ F1.2, AGC ON; 0 lux with IR
Focal Length 2.8mm
Angle Adjustment Pan: 0°~360°; Tilt:0°~75°; Rotation: 0°~360°
IR Distance 20 ~ 30 m
Wide Dynamic Range 120dB
Video Compression H.265 / H.264 / MJPEG
Video Resolution 8MP ( 3840 × 2160 ),2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ), 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240
Video Frame Rate
Main Stream 60Hz : 8MP(1~30fps)/ 2K(1~30fps)/ 3MP(1~30fps)/1080P(1~30fps)/ 720P(1~30fps)
50Hz : 8MP(1~25fps)/2K(1~25fps)/3MP(1~25fps)/1080P(1~25fps)/ 720P(1~25fps)
Sub Stream 60Hz : 1080P/720P/D1(1~30fps); 50HZ:1080P/720P/D1(1~25fps)
Third Stream 60Hz : 720P/D1/CIF/480×240 (1~30fps);
50HZ: 720P/D1/CIF/480×240 (1~25fps)
Video Bitrate 128 Kbps ~ 12 Mbps
BLC Mode Support
HLC Support
ROI Each ROI to be configured separately
Digital Noise Reduction 3D DNR
Defog Support
Audio Compression G711A / U
Audio In MIC IN × 1; built-in MIC × 1
Face Detection Pupil distance of a facial image over 20 pixel can be detected
Face Capturing By precision detecting, tracing, capturing, scoring and screening the moving faces to get the most effective face snapshots
Panorama Capturing Support panorama capturing and self-defined information overlay, like device ID, time, etc.
Intelligent Light Compensation Built-in high efficient white light LEDs, time switch available
Ethernet RJ45
Network Protocol UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, 802.1x, UPnP, HTTPs, QoS
Storage Network remote storage; micro SD card storage
Storage Card Built-in micro SD card slot; up to 128GB
General Function Watermark, IP address filtering, video mask, heartbeat, password protection
Mobile iPhone, Android
Video Output CVBS output (BNC × 1)
Power Supply DC12V/PoE
Power Consumption < 6W
Operating Temperature – 30 °C ~ 60 (-22°F~140°F) Humidity: less than 95 % (non condensing)
Ingress Protection IP 67
Dimensions Φ 94.6mm × 82.8mm
Weight Approx. 0.47KG

Additional information

Weight 3 lbs
Dimensions 6 × 6 × 6 in
